AWS Lambda —3 pro tips for working with Kinesis streams

At Yubl, we arrived at a non-trivial serverless architecture where Lambda and Kinesis became a prominent feature of this architecture.

Whilst our experience using Lambda with Kinesis was great in general, there was a couple of lessons that we had to learn along the way. Here are 3 useful tips to help you avoid some of the pitfalls we fell into and accelerate your own adoption of Lambda and Kinesis.

Consider partial failures

From the Lambda documentation:

AWS Lambda polls your stream and invokes your Lambda function. Therefore, if a Lambda function fails, AWS Lambda attempts to process the erring batch of records until the time the data expires…

Because the way Lambda functions are retried, if you allow your function to err on partial failures then the default behavior is to retry the entire batch until success or the data expires from the stream.

To decide if this default behavior is right for you, you have to answer certain questions:

  • can events be processed more than once?
  • what if those partial failures are persistent? (perhaps due to a bug in the business logic that is not handling certain edge cases gracefully)
  • is it more important to process every event till success than keeping the overall system real-time?

In the case of Yubl (which was a social networking app with a timeline feature similar to Twitter) we found that for most of our use cases it’s more important to keep the system flowing than to halt processing for any failed events, even if for a minute.

For instance, when you create a new post, we would distribute it to all of your followers by processing the yubl-posted event. The 2 basic choices we’re presented with are:

  1. allow errors to bubble up and fail the invocation—we give every event every opportunity to be processed; but if some events fail persistently then no one will receive new posts in their feed and the system appears unavailable
  2. catch and swallow partial failures—failed events are discarded, some users will miss some posts but the system appears to be running normally to users (even affected users might not realize that they had missed some posts)

(of course, it doesn’t have to be a binary choice, there’s plenty of room to add smarter handling for partial failures, which we will discuss shortly)

We encapsulated these 2 choices as part of our tooling so that we get the benefit of reusability and the developers can make an explicit choice (and the code makes that choice obvious to anyone reading it later on) for every Kinesis processor they create.

You would probably apply different choices depending on the problem you’re solving, the important thing is to always consider how partial failures would affect your system as a whole.

Use dead letter queues (DLQ)

AWS announced support for Dead Letter Queues (DLQ) at the end of 2016, however, at the time of writing this support only extends to asynchronous invocations (SNS, S3, IOT, etc.) but not poll-based invocations such as Kinesis and DynamoDB streams.

That said, there’s nothing stopping you from applying the DLQ concept yourself.

First, let’s roll back the clock to a time when we didn’t have Lambda. Back then, we’d use long running applications to poll Kinesis streams ourselves. Heck, I even wrote my own producer and consumer libraries because when AWS rolled out Kinesis they totally ignored anyone not running on the JVM!

Lambda has taken over a lot of the responsibilities—polling, tracking where you are in the stream, error handling, etc.—but as we have discussed above it doesn’t remove you from the need to think for yourself. Nor does it change what good looks like for a system that processes Kinesis events, which for me must have at least these 3 qualities:

  • it should be real-time (most domains consider real-time as “within a few seconds”)
  • it should retry failed events, but retries should not violate the realtime constraint on the system
  • it should be possible to retrieve events that could not be processed so someone can investigate root cause or provide manual intervention

Back then, my long running application would:

  1. poll Kinesis for events
  2. process the events by passing them to a delegate function (your code)
  3. failed events are retried 2 additional times
  4. after the 2 retries are exhausted, they are saved into a SQS queue
  5. record the last sequence number of the batch so that we don’t lose the current progress if the host VM dies or the application crashes
  6. another long running application (perhaps on another VM) would poll the SQS queue for events that couldn’t be process realtime
  7. process the failed events by passing them to the same delegate function as above (your code)
  8. after the max no. of retrievals the events are passed off to a DLQ
  9. this triggers CloudWatch alarms and someone can manually retrieve the event from the DLQ to investigate

A Lambda function that processes Kinesis events should also:

  • retry failed events X times depending on processing time
  • send failed events to a DLQ after exhausting X retries

Since SNS already comes with DLQ support, you can simplify your setup by sending the failed events to a SNS topic instead—Lambda would then process it a further 3 times before passing it off to the designated DLQ.

Avoid “hot” streams

We found that when a Kinesis stream has 5 or more Lambda function subscribers we would start to see lots ReadProvisionedThroughputExceeded errors in CloudWatch. Fortunately these errors are silent to us as they happen to (and are handled by) the Lambda service polling the stream.

However, we occasionally see spikes in the GetRecords.IteratorAge metric, which tells us that a Lambda function will sometimes lag behind. This did not happen frequently enough to present a problem but the spikes were unpredictable and did not correlate to spikes in traffic or number of incoming Kinesis events.

Increasing the no. of shards in the stream made matters worse and the no. of ReadProvisionedThroughputExceeded increased proportionally.


According to the Kinesis documentation

Each shard can support up to 5 transactions per second for reads, up to a maximum total data reads of 2 MB per second.

and Lambda documentation

If your stream has 100 active shards, there will be 100 Lambda functions running concurrently. Then, each Lambda function processes events on a shard in the order that they arrive.

One would assume that each of the aforementioned Lambda functions would be polling its shard independently. Since the problem is having too many Lambda functions poll the same shard, it makes sense that adding new shards will only escalate the problem further.


“All problems in computer science can be solved by another level of indirection.”

—David Wheeler

After speaking to the AWS support team about this, the only advice we received (and one that we had already considered) was to apply the fan out pattern by adding another layer of Lambda function who would distribute the Kinesis events to others.

Whilst this is simple to implement, it has some downsides:

  • it vastly complicates the logic for handling partial failures (see above)
  • all functions now process events at the rate of the slowest function, potentially damaging the realtime-ness of the system

We also considered and discounted several other alternatives, including:

  • have one stream per subscriber—this has a significant cost implication, and more importantly it means publishers would need to publish the same event to multiple Kinesis streams in a “transaction” with no easy way to rollback (since you can’t unpublish an event in Kinesis) on partial failures
  • roll multiple subscriber logic into one—this corrodes our service boundary as different subsystems are bundled together to artificially reduce the no. of subscribers

In the end, we didn’t find a truly satisfying solution and decided to reconsider if Kinesis was the right choice for our Lambda functions on a case by case basis.

  • for subsystems that do not have to be realtime, use S3 as source instead—all our Kinesis events are persisted to S3 via Kinesis Firehose, the resulting S3 files can then be processed by these subsystems, eg. Lambda functions that stream events to Google BigQuery for BI
  • for work that are task-based (ie, order is not important), use SNS/SQS as source instead—SNS is natively supported by Lambda, and we implemented a proof-of-concept architecture for processing SQS events with recursive Lambda functions, with elastic scaling; now that SNS has DLQ support (it was not available at the time) it would definitely be the preferred option provided that its degree of parallelism would not flood and overwhelm downstream systems such as databases, etc.
  • for everything else, continue to use Kinesis and apply the fan out pattern as an absolute last resort

Wrapping up…

So there you have it, 3 pro tips from a group of developers who have had the pleasure of working extensively with Lambda and Kinesis.

I hope you find this post useful, if you have any interesting observations or learning from your own experience working with Lambda and Kinesis, please share them in the comments section below.

Links

Yubl’s road to serverless — Part 1, Overview

Yubl’s road to serverless — Part 2, Testing and CI/CD

Yubl’s road to serverless — Part 3, Ops

AWS Lambda — use recursive functions to process SQS messages, Part 1

AWS Lambda — use recursive functions to process SQS messages, Part 2

AWS Lambda – build yourself a URL shortener in 2 hours

An interesting requirement came up at work this week where we discussed potentially having to run our own URL Shortener because the Universal Links mechanism (in iOS 9 and above) requires a JSON manifest at

https://domain.com/apple-app-site-association

Since the OS doesn’t follow redirects this manifest has to be hosted on the URL shortener’s root domain.

Owing to a limitation on AppsFlyer it’s currently not able to shorten links when you have Universal Links configured for your app. Whilst we can switch to another vendor it means more work for our (already stretched) client devs and we really like AppsFlyer‘s support for attributions.

Which brings us back to the question

“should we build a URL shortener?”

swiftly followed by

“how hard can it be to build a scalable URL shortener in 2017?”

Well, turns out it wasn’t hard at all

Lambda FTW

For this URL shortener we’ll need several things:

  1. a GET /{shortUrl} endpoint that will redirect you to the original URL
  2. a POST / endpoint that will accept an original URL and return the shortened URL
  3. an index.html page where someone can easily create short URLs
  4. a GET /apple-app-site-association endpoint that serves a static JSON response

all of which can be accomplished with API Gateway + Lambda.

Overall, this is the project structure I ended up with:

  • using the Serverless framework’s aws-nodejs template
  • each of the above endpoint have a corresponding handler function
  • the index.html file is in the static folder
  • the test cases are written in such a way that they can be used both as integration as well as acceptance tests
  • there’s a build.sh script which facilitates running
    • integration tests, eg ./build.sh int-test {env} {region} {aws_profile}
    • acceptance tests, eg ./build.sh acceptance-test {env} {region} {aws_profile}
    • deployment, eg ./build.sh deploy {env} {region} {aws_profile}

Get /apple-app-site-association endpoint

Seeing as this is a static JSON blob, it makes sense to precompute the HTTP response and return it every time.

POST / endpoint

For an algorithm to shorten URLs, you can find a very simple and elegant solution on StackOverflow. All you need is an auto-incremented ID, like the ones you normally get with RDBMS.

However, I find DynamoDB a more appropriate DB choice here because:

  • it’s a managed service, so no infrastructure for me to worry about
  • OPEX over CAPEX, man!
  • I can scale reads & writes throughput elastically to match utilization level and handle any spikes in traffic

but, DynamoDB has no such concept as an auto-incremented ID which the algorithm needs. Instead, you can use an atomic counter to simulate an auto-incremented ID (at the expense of an extra write-unit per request).

GET /{shortUrl} endpoint

Once we have the mapping in a DynamoDB table, the redirect endpoint is a simple matter of fetching the original URL and returning it as part of the Location header.

Oh, and don’t forget to return the appropriate HTTP status code, in this case a 308 Permanent Redirect.

GET / index page

Finally, for the index page, we’ll need to return some HTML instead (and a different content-type to go with the HTML).

I decided to put the HTML file in a static folder, which is loaded and cached the first time the function is invoked.

Getting ready for production

Fortunately I have had plenty of practice getting Lambda functions to production readiness, and for this URL shortener we will need to:

  • configure auto-scaling parameters for the DynamoDB table (which we have an internal system for managing the auto-scaling side of things)
  • turn on caching in API Gateway for the production stage

Future Improvements

If you put in the same URL multiple times you’ll get back different short-urls, one optimization (for storage and caching) would be to return the same short-url instead.

To accomplish this, you can:

  1. add GSI to the DynamoDB table on the longUrl attribute to support efficient reverse lookup
  2. in the shortenUrl function, perform a GET with the GSI to find existing short url(s)

I think it’s better to add a GSI than to create a new table here because it avoids having “transactions” that span across multiple tables.

Useful Links

Slides for my AWS user group talk – AWS Lambda from the trenches

Hello, just a quick note to say thanks to everyone who attended the AWS user group meetup last night, was a pleasure to talk to many of you afterwards. As promised, here are the slides for my talk from last night.

Yubl’s road to Serverless architecture – Part 3 – ops

The Road So Far

part 1 : overview

part 2 : testing and continuous delivery strategies



A couple of folks asked me about our strategy for monitoring, logging, etc. after part 2, and having watched Chris Swan talk about “Serverless Operations is not a Solved Problem” at the Serverless meetup it’s a good time for us to talk about how we approached ops with AWS Lambda.



NoOps != No Ops

The notion of “NoOps” have often been mentioned with serverless technologies (I have done it myself), but it doesn’t mean that you no longer have to worry about ops.

To me, “ops” is the umbrella term for everything related to keeping my systems operational and performing within acceptable parameters, including (but not limited to) resource provisioning, configuration management, monitoring and being on-hand to deal with any live issues. The responsibilities of keeping the systems up and running will always exist regardless whether your software is running on VMs in the cloud, on-premise hardware, or as small Lambda functions.

Within your organization, someone needs to fulfill these responsibilities. It might be that you have a dedicated ops team, or perhaps your developers will share those responsibilities.

NoOps to me, means no ops specialization in my organization – ie. no dedicated ops team – because the skills and efforts required to fulfill the ops responsibilities do not justify the need for such specialization. As an organization it’s in your best interest to delay such specialization for as long as you can both from a financial point of view and also, perhaps more importantly, because Conway’s law tells us that having an ops team is the surefire way to end up with a set of operational procedures/processes, tools and infrastructure whose complexity will in turn justify the existence of said ops team.

At Yubl, as we migrated to a serverless architecture our deployment pipeline became more streamlined, our toolchain became simpler and we found less need for a dedicated ops team and were in the process of disbanding our ops team altogether.



Logging

Whenever you write to the stdout from your Lambda function – eg. when you do console.log in your nodejs code – it ends up in the function’s Log Group in CloudWatch Logs.

Centralised Logging

However, logs are not easily searchable, and once you have a dozen Lambda functions you will want to collect them in one central place. The ELK stack is the de facto standard for centralised logging these days, you can run your own ELK stack on EC2, and elastic.co also offers a hosted version of Elasticsearch and Kibana.

To ship your logs from CloudWatch Logs to ELK you can subscribe the Log Group to a cloudwatch-logs-to-elk function that is responsible for shipping the logs.

You can subscribe the Log Group manually via the AWS management console.

But, you don’t want a manual step everyone needs to remember every time they create a new Lambda function. Instead, it’s better to setup a rule in CloudWatch Events to invoke a subscribe-log-group Lambda function to set up the subscription for new Log Groups.

2 things to keep in mind:

  • lots services create logs in CloudWatch Logs, so you’d want to filter Log Groups by name, Lambda function logs have the prefix /aws/lambda/
  • don’t subscribe the Log Group for the cloudwatch-logs-to-elk function (or whatever you decide to call it), otherwise you create an infinite loop for the cloudwatch-logs-to-elk function where its own logs will trigger itself and produce more logs and so on



Distributed Tracing

Having all your logs in one easily searchable place is great, but as your architecture expands into more and more services that depends on one another you will need to correlated logs from different services to understand all the events that occurred during one user request.

For instance, when a user creates a new post in the Yubl app we distribute the post to all of the user’s followers. Many things happen along this flow:

  1. user A’s client calls the legacy API to create the new post
  2. the legacy API fires a yubl-posted event into a Kinesis stream
  3. the distribute-yubl function is invoked to handle this event
  4. distribute-yubl function calls the relationship-api to find user A’s followers
  5. distribute-yubl function then performs some business logic, group user A’s followers into batches and for each batch fires a message to a SNS topic
  6. the add-to-feed function is invoked for each SNS message and adds the new post to each follower’s feed

If one of user A’s followers didn’t receive his new post in the feed then the problem can lie in a number of different places. To make such investigations easier we need to be able to see all the relevant logs in chronological order, and that’s where correlation IDs (eg. initial request-id, user-id, yubl-id, etc.) come in.

Because the handling of the initial user request flows through API calls, Kinesis events and SNS messages, it means the correlation IDs also need to be captured and passed through API calls, Kinesis events and SNS messages.

Our approach was to roll our own client libraries which will pass the captured correlation IDs along.

Capturing Correlation IDs

All of our Lambda functions are created with wrappers that wraps your handler code with additional goodness such as capturing the correlation IDs into a global.CONTEXT object (which works because nodejs is single-threaded).

Forwarding Correlation IDs

Our HTTP client library is a thin wrapper around the superagent HTTP client and injects the captured correlation IDs into outgoing HTTP headers.

We also have a client library for publishing Kinesis events, which can inject the correlation IDs into the record payload.

For SNS, you can include the correlation IDs as message attributes when publishing a message.

Zipkin and Amazon X-Ray

Since then, AWS has announced x-ray but it’s still in preview so I have not had a chance to see how it works in practice, and it doesn’t support Lambda at the time of writing.

There is also Zipkin, but it requires you to run additional infrastructure on EC2 and whilst it has wide range of support for instrumentation the path to adoption in the serverless environment (where you don’t have or need traditional web frameworks) is not clear to me.



Monitoring

Out of the box you get a number of basic metrics from CloudWatch – invocation counts, durations, errors, etc.

You can also publish custom metrics to CloudWatch (eg. user created, post viewed) using the AWS SDK. However, since these are HTTP calls you have to be conscious of the latencies they’ll add for user-facing functions (ie. those serving APIs). You can mitigate the added latencies by publishing them in a fire-and-forget fashion, and/or budgeting the amount of time (say, to a max of 50ms) you can spend publishing metrics at the end of a request.

Because you have to do everything during the invocation of a function, it forces you to make trade offs.

Another approach is to take a leaf from Datadog’s book and use special log messages and process them after the fact. For instance, if you write logs in the format MONITORING|epoch_timestamp|metric_value|metric_type|metric_name like below..

console.log(“MONITORING|1489795335|27.4|latency|user-api-latency”);

console.log(“MONITORING|1489795335|8|count|yubls-served”);

then you can process these log messages (see Logging section above) and publish them as metrics instead. With this approach you’ll be trading off liveness of metrics for less API latency overhead.

Of course, you can employ both approaches in your architecture and use the appropriate one for each situation:

  • for functions on the critical path (that will directly impact the latency your users experience), choose the approach of publishing metrics as special log messages;
  • for other functions (cron jobs, kinesis processors, etc.) where invocation duration doesn’t significantly impact a user’s experience, publish metrics as part of the invocation

Dashboards + Alerts

We have a number of dashboards setup in CloudWatch as well as Graphite (using hostedgraphite, for our legacy stack running on EC2), and they’re displayed on large monitors near the server team area. We also set up alerts against various metrics such as API latencies and error count, and have opsgenie setup to alert whoever’s on-call that week.

Consider alternatives to CloudWatch

Whilst CloudWatch is good, cost-effective solution for monitoring (in some cases the only way to get metrics out of AWS services such as Kinesis and DynamoDB) it has its drawbacks.

Its UI and customization is not on-par with competitors such as Graphite, Datadog and Sysdig, and it lacks advanced features such as anomaly detection and finding correlations that you find in Stackdrvier and Wavefront.

The biggest limitation however, is that CloudWatch metrics are only granular to the minute. It means your time to discovery of issues is measured in mins (you need a few data points to separate real issues that require manual intervention from temporary blips) and consequently your time to recover is likely to be measured in tens of mins. As your scale up and the cost of unavailability goes up you need to invest efforts to cut down both times, which might mean that you need more granular metrics than CloudWatch is able to give you.

Another good reason for not using CloudWatch is that, you really don’t want your monitoring system to fail at the same time as the system it monitors. Over the years we have experienced a number of AWS outages that impacted both our core systems running on EC2 as well as CloudWatch itself. As our system fails and recovers we don’t have the visibility to see what’s happening and how it’s impacting our users.



Config Management

Whatever approach you use for config management you should always ensure that:

  • sensitive data (eg. credentials, connection strings) are encrypted in-flight, and at rest
  • access to sensitive data should be based on roles
  • you can easily and quickly propagate config changes

Nowadays, you can add environment variables to your Lambda functions directly, and have them encrypted with KMS.

This was the approach we started with, albeit using environment variables in the Serverless framework since it wasn’t a feature of the Lambda service at the time. After we had a dozen functions that share config values (eg. MongoDB connection strings) this approach became cumbersome and it was laborious and painfully slow to propagate config changes manually (by updating and re-deploying every function that require the updated config value).

It was at this point in our evolution that we moved to a centralised config service. Having considered consul (which I know a lot of folks use) we decided to write our own using API Gateway, Lambda and DynamoDB because:

  • we don’t need many of consul‘s features, only the kv store
  • consul is another thing we’d have to run and manage
  • consul is another thing we’d have to learn
  • even running consul with 2 nodes (you need some redundancy for production) it is still order of magnitude more expensive

Sensitive data are encrypted (by a developer) using KMS and stored in the config API in its encrypted form, when a Lambda function starts up it’ll ask the config API for the config values it needs and it’ll use KMS to decrypt the encrypted blob.

We secured access to the config API with api keys created in API Gateway, in the event these keys are compromised attackers will be able to update config values via this API. You can take this a step further (which we didn’t get around to in the end) by securing the POST endpoint with IAM roles, which will require developers to make signed requests to update config values.

Attackers can still retrieve sensitive data in encrypted form, but they will not be able to decrypt them as KMS also requires role-based access.

client library

As most of our Lambda functions need to talk to the config API we invested efforts into making our client library really robust and baked in caching support and periodic polling to refresh config values from the source.



So, that’s it folks, hope you’ve enjoyed this post, click here to see the rest of the series.

The emergence of AWS Lambda and other serverless technologies have significantly simplified the skills and tools required to fulfil the ops responsibilities inside an organization. However, this new paradigm has also introduced new limitations and challenges for existing toolchains and requires us to come up with new answers. Things are changing at an incredibly fast pace, and I for one am excited to see what new practices and tools emerge from this space!

Yubl’s road to Serverless architecture – Part 2 – Testing and CI/CD

Note: see here for the rest of the series.



Having spoken to quite a few people about using AWS Lambda in production, testing and CI/CD are always high up the list of questions, so I’d like to use this post to discuss the approaches that we took at Yubl.

Please keep in mind that this is a recollection of what we did, and why we chose to do things that way. I have heard others advocate very different approaches, and I’m sure they too have their reasons and their approaches no doubt work well for them. I hope to give you as much context (or, the “why”) as I can so you can judge whether or not our approach would likely work for you, and feel free to ask questions in the comments section.



Testing

In Growing Object-Oriented Software, Guided by Tests, Nat Pryce and Steve Freeman talked about the 3 levels of testing [Chapter 1]:

  1. Acceptance – does the whole system work?
  2. Integration – does our code work against code we can’t change?
  3. Unit – do our objects do the right thing, are they easy to work with?

As you move up the level (acceptance -> unit) the speed of the feedback loop becomes faster, but you also have less confidence that your system will work correctly when deployed.

Favour Acceptance and Integration Tests

With the FAAS paradigm, there are more “code we can’t change” than ever (AWS even describes Lambda as the “glue for your cloud infrastructure”) so the value of integration and acceptance tests are also higher than ever. Also, as the “code we can’t change” are easily accessible as service, it also makes these tests far easier to orchestrate and write than before.

The functions we tend to write were fairly simple and didn’t have complicated logic (most of the time), but there were a lot of them, and they were loosely connected through messaging systems (Kinesis, SNS, etc.) and APIs. The ROI for acceptance and integration tests are therefore far greater than unit tests.

It’s for these reason that we decided (early on in our journey) to focus our efforts on writing acceptance and integration tests, and only write unit tests where the internal workings of a Lambda function is sufficiently complex.

No Mocks

In Growing Object-Oriented Software, Guided by TestsNat Pryce and Steve Freeman also talked about why you shouldn’t mock types that you can’t change [Chapter 8], because…

…We find that tests that mock external libraries often need to be complex to get the code into the right state for the functionality we need to exercise.

The mess in such tests is telling us that the design isn’t right but, instead of fixing the problem by improving the code, we have to carry the extra complexity in both code and test…

…The second risk is that we have to be sure that the behaviour we stub or mock matches what the external library will actually do…

Even if we get it right once, we have to make sure that the tests remain valid when we upgrade the libraries…

I believe the same principles apply here, and that you shouldn’t mock services that you can’t change.

Integration Tests

Lambda function is ultimately a piece of code that AWS invokes on your behalf when some input event occurs. To test that it integrates correctly with downstream systems you can invoke the function from your chosen test framework (we used Mocha).

Since the purpose is to test the integration points, so it’s important to configure the function to use the same downstream systems as the real, deployed code. If your function needs to read from/write to a DynamoDB table then your integration test should be using the real table as opposed to something like dynamodb-local.

It does mean that your tests can leave artefacts in your integration environment and can cause problems when running multiple tests in parallel (eg. the artefacts from one test affect results of other tests). Which is why, as a rule-of-thumb, I advocate:

  • avoid hard-coded IDs, they often cause unintentional coupling between tests
  • always clean up artefacts at the end of each test

The same applies to acceptance tests.

Acceptance Tests

(this picture is slightly misleading in that the Mocha tests are not invoking the Lambda function programmatically, but rather invoking it indirectly via whatever input event the Lambda function is configured with – API Gateway, SNS, Kinesis, etc. More on this later.)

…Wherever possible, an acceptance test should exercise the system end-to-end without directly calling its internal code.

An end-to-end test interacts with the system only from the outside: through its interface…

…We prefer to have the end-to-end tests exercise both the system and the process by which it’s built and deployed

This sounds like a lot of effort (it is), but has to be done anyway repeatedly during the software’s lifetime…

– Growing Object-Oriented Software, Guided by Tests [Chapter 1]

Once the integration tests complete successfully, we have good confidence that our code will work correctly when it’s deployed. The code is deployed, and the acceptance tests are run against the deployed system end-to-end.

Take our Search API for instance, one of the acceptance criteria is “when a new user joins, he should be searchable by first name/last name/username”.

The acceptance test first sets up the test condition – a new user joins – by interacting with the system from the outside and calling the legacy API like the client app would. From here, a new-user-joined event will be fired into Kinesis; a Lambda function would process the event and add a new document in the User index in CloudSearch; the test would validate that the user is searchable via the Search API.

Avoid Brittle Tests

Because a new user is added to CloudSearch asynchronously via a background process, it introduces eventual consistency to the system. This is a common challenge when you decouple features through events/messages. When testing these eventually consistent systems, you should avoid waiting fixed time periods (see protip 5 below) as it makes your tests brittle.

In the “new user joins” test case, this means you shouldn’t write tests that:

  1. create new user
  2. wait 3 seconds
  3. validate user is searchable

and instead, write something along the lines of:

  1. create new user
  2. validate user is searchable with retries
    1. if expectation fails, then wait X seconds before retrying
    2. repeat
    3. allow Y retries before failing the test case

Sharing test cases for Integration and Acceptance Testing

We also found that, most of the time the only difference between our integration and acceptance tests is how our function code is invoked. Instead of duplicating a lot of code and effort, we used a simple technique to allow us to share the test cases.

Suppose you have a test case such as the one below.

The interesting bit is on line 22:

let res = yield when.we_invoke_get_all_keys(region);

In the when module, the function we_invoke_get_all_keys will either

  • invoke the function code directly with a stubbed context object, or
  • perform a HTTP GET request against the deployed API

depending on the value of process.env.TEST_MODE, which is an environment variable that is passed into the test via package.json (see below) or the bash script we use for deployment (more on this shortly).



Continuous Integration + Continuous Delivery

Whilst we had around 170 Lambda functions running production, many of them work together to provide different features to the app. Our approach was to group these functions such that:

  • functions that form the endpoints of an API are grouped in a project
  • background processing functions for a feature are grouped in a project
  • each project has its own repo
  • functions in a project are tested and deployed together

The rationale for this grouping strategy is to:

  • achieve high cohesion for related functions
  • improve code sharing where it makes sense (endpoints of an API are likely to share some logic since they operate within the same domain)

Although functions are grouped into projects, they can still be deployed individually. We chose to deploy them as a unit because:

  • it’s simple, and all related functions (in a project) have the same version no.
  • it’s difficult to detect if a change to shared code will impact which functions
  • deployment is fast, it makes little difference speed-wise whether we’re deploy one function or five functions



For example, in the Yubl app, you have a feed of posts from people you follow (similar to your Twitter timeline).

To implement this feature there was an API (with multiple endpoints) as well as a bunch of background processing functions (connected to Kinesis streams and SNS topics).

The API has two endpoints, but they also share a common custom auth function, which is included as part of this project (and deployed together with the get and get-yubl functions).

The background processing (initially only Kinesis but later expanded to include SNS as well, though the repo wasn’t renamed) functions have many shared code, such as the distribute module you see below, as well as a number of modules in the lib folder.

All of these functions are deployed together as a unit.

Deployment Automation

We used the Serverless framework to do all of our deployments, and it took care of packaging, uploading and versioning our Lambda functions and APIs. It’s super useful and took care of most of the problem for us, but we still needed a thin layer around it to allow AWS profile to be passed in and to include testing as part of the deployment process.

We could have scripted these steps on the CI server, but I have been burnt a few times by magic scripts that only exist on the CI server (and not in source control). To that end, every project has a simple build.sh script (like the one below) which gives you a common vocabulary to:

  • run unit/integration/acceptance tests
  • deploy your code

Our Jenkins build configs do very little and just invoke this script with different params.

Continuous Delivery

To this day I’m still confused by Continuous “Delivery” vs Continuous “Deployment”. There seems to be several interpretations, but this is the one that I have heard the most often:

Regardless of which definition is correct, what was most important to us was the ability to deploy our changes to production quickly and frequently.

Whilst there were no technical reasons why we couldn’t deploy to production automatically, we didn’t do that because:

  • it gives QA team opportunity to do thorough tests using actual client apps
  • it gives the management team a sense of control over what is being released and when (I’m not saying if this is a good or bad thing, but merely what we wanted)

In our setup, there were two AWS accounts:

  • production
  • non-prod, which has 4 environments – dev, test, staging, demo

(dev for development, test for QA team, staging is a production-like, and demo for private beta builds for investors, etc.)

In most cases, when a change is pushed to Bitbucket, all the Lambda functions in that project are automatically tested, deployed and promoted all the way through to the staging environment. The deployment to production is a manual process that can happen at our convenience and we generally avoid deploying to production on Friday afternoon (for obvious reasons ).



Conclusions

The approaches we have talked about worked pretty well for our team, but it was not without drawbacks.

In terms of development flow, the focus on integration and acceptance tests meant slower feedback loops and the tests take longer to execute. Also, because we don’t mock downstream services it means we couldn’t run tests without internet connection, which is an occasional annoyance when you want to work during commute.

These were explicit tradeoffs we made, and I stand by them even now and AFAIK everyone in the team feels the same way.



In terms of deployment, I really missed the ability to do canary releases. Although this is offset by the fact that our user base was still relatively small and the speed with which one can deploy and rollback changes with Lambda functions was sufficient to limit the impact of a bad change.

Whilst AWS Lambda and API Gateway doesn’t support canary releases out-of-the-box it is possible to do a DIY solution for APIs using weighted routing in Route53. Essentially you’ll have:

  • a canary stage for API Gateway and associated Lambda function
  • deploy production builds to the canary stage first
  • use weighted routing in Route53 to direct X% traffic to the canary stage
  • monitor metrics, and when you’re happy with the canary build, promote it to production

Again, this would only work for APIs and not for background processing (SNS, Kinesis, S3, etc.).



So that’s it folks, hope you’ve enjoyed this post, feel free to leave a comment if you have any follow up questions or tell me what else you’d like to hear about in part 3.

Ciao!



Links
