AWS Lambda – use recursive function to process SQS messages (Part 2)

First of all, apologies for taking months to write this up since part 1, I have been extremely busy since joining Yubl. We have done a lot of work with AWS Lambda and I hope to share more of the lessons we have learnt soon, but for now take a look at this slidedeck to get a flavour.



At the end of part 1 we have a recursive Lambda function that will:

  1. fetch messages from SQS using long-polling
  2. process any received messages
  3. recurse by invoking itself asynchronously

however, on its own there are a number of problems:

  • any unhandled exceptions will kill the loop
  • there’s no way to scale the no. of processing loops elastically



We can address these concerns with a simple mechanism where:

  • a DynamoDB table stores a row for each loop that should be running
  • when scaling up, a new row is added to the table, and a new loop is started with the Hash Key (let’s call it a token) as input;
  • on each recursion, the looping function will check if its token is still valid
    • if yes, then the function will upsert a last_used timestamp against its token
    • if not (ie, the token is deleted) then terminates the loop
  • when scaling down, one of the tokens is chosen at random and deleted from the table, which causes the corresponding loop to terminate at the end of its current recursion (see above)
  • another Lambda function is triggered every X mins to look for tokens whose last_used timestamp is older than some threshold, and starts a new loop in its place

Depending on how long it takes the processing function to process all its SQS messages – limited by the max 5 min execution time – you can either adjust the threshold accordingly. Alternatively, you can provide another GUID when starting each loop (say, a loop_id?) and extend the loop’s token check to make sure the loop_id associated with its token matches its own.



High Level Overview

To implement this mechanism, we will need a few things:

  • a DynamoDB table to store the tokens
  • a function to look for dead loops restart them
  • a CloudWatch event to trigger the restart function every X mins
  • a function to scale_up the no. of processing loops
  • a function to scale_down the no. of processing loops
  • CloudWatch alarm(s) to trigger scaling activity based on no. of messages in the queue
  • SNS topics for the alarms to publish to, which in turn triggers the scale_up and scale_down functions accordingly*

* the SNS topics are required purely because there’s no support for CloudWatch alarms to trigger Lambda functions directly yet.

architecture

A working code sample is available on github which includes:

  • handler code for each of the aforementioned functions
  • s-resources-cf.json that will create the DynamoDB table when deployed
  • _meta/variables/s-variables-*.json files which also specifies the name of the DynamoDB table (and referenced by s-resources-cf.json above)

I’ll leave you to explore the code sample at your own leisure, and instead touch on a few of the intricacies.



Setting up Alarms

Assuming that your queue is mostly empty as your processing is keeping pace with the rate of new items, then a simple staggered set up should suffice here, for instance:

cw-alarm-2

Each of the alarms would send notification to the relevant SNS topic on ALARM and OK.

cw-alarm-1



Verifying Tokens

Since there’s no way to message a running Lambda function directly, we need a way to signal it to stop recursing somehow, and this is where the DynamoDB table comes in.

At the start of each recursion, the processing-msg function will check against the table to see if its token still exists. And since the table is also used to record a heartbeat from the function (for the restart function to identify failed recursions), it also needs to upsert the last_used timestamp against the token.

We can combine the two ops in one conditional write, which will fail if the token doesn’t exist, and that error will terminate the loop.

ps. I made the assumption in the sample code that processing the SQS messages is quick, hence why the timeout setting for the process-msg function is 30s (20s long polling + 10s processing) and the restart function’s threshold is a very conservative 2 mins (it can be much shorter even after you take into account the effect of eventual consistency).

If your processing logic can take some time to execute – bear in mind that the max timeout allowed for a Lambda function is 5 mins – then here’s a few options that spring to mind:

  1. adjust the restart function’s threshold to be more than 5 mins : which might not be great as it lengthens your time to recovery when things do go wrong;
  2. periodically update the last_used timestamp during processing : which also needs to be conditional writes, whilst swallowing any errors;
  3. add an loop_id in to the DynamoDB table and include it in the ConditionExpression : that way, you keep the restart function’s threshold low and allow the process-msg function to occasionally overrun; when it does, a new loop is started in its place and takes over its token with a new loop_id so that when the overrunning instance finishes it’ll be stopped when it recurses (and fails to verify its token because the loop_id no longer match)

Both option 2 & 3 strike me as reasonable approaches, depending on whether your processing logic are expected to always run for some time (eg, involves some batch processing) or only in unlikely scenarios (occasionally slow third-party API calls).



Scanning for Failed Loops

The restart function performs a table scan against the DynamoDB table to look for tokens whose last_used timestamp is either:

  • not set : the process-msg function never managed to set it during the first recursion, perhaps DynamoDB throttling issue or temporary network issue?
  • older than threshold : the process-msg function has stopped for whatever reason

By default, a Scan operation in DynamoDB uses eventually consistent read, which can fetch data that are a few seconds old. You can set the ConsistentRead parameter to true; or, be more conservative with your thresholds.

Also, there’s a size limit of 1mb of scanned data per Scan request. So you’ll need to perform the Scan operation recursively, see here.



Find out QueueURL from SNS Message

In the s-resources-cf.json file, you might have noticed that the DynamoDB table has the queue URL of the SQS queue as hash key. This is so that we could use the same mechanism to scale up/down & restart processing functions for many queues (see the section below).

But this brings up a new question: “when the scale-up/scale-down functions are called (by CloudWatch Alarms, via SNS), how do we work out which queue we’re dealing with?”

When SNS calls our function, the payload looks something like this:

which contains all the information we need to workout the queue URL for the SQS queue in question.

We’re making an assumption here that the triggered CloudWatch Alarm exist in the same account & region as the scale-up and scale-down functions (which is a pretty safe bet I’d say).



Knowing when NOT to Scale Down

Finally – and these only apply to the scale-down function – there are two things to keep in mind when scaling down:

  1. leave at least 1 processing loop per queue
  2. ignore OK messages whose old state is not ALARM

The first point is easy, just check if the query result contains more than 1 token.

The second point is necessary because CloudWatch Alarms have 3 states – OK, INSUFFICIENT_DATA and ALARM – and we only want to scale down when transitioned from ALARM => OK.



Taking It Further

As you can see, there is a fair bit of set up involved. It’d be a waste if we have to do the same for every SQS queue we want to process.

Fortunately, given the current set up there’s nothing stopping you from using the same infrastructure to manage multiple queues:

  • the DynamoDB table is keyed to the queue URL already, and
  • the scale-up and scale-down functions can already work with CloudWatch Alarms for any SQS queues

Firstly, you’d need to implement additional configuration so that given a queue URL you can work out which Lambda function to invoke to process messages from that queue.

Secondly, you need to decide between:

  1. use the same recursive function to poll SQS, but forward received messages to relevant Lambda functions based on the queue URL, or
  2. duplicate the recursive polling logic in each Lambda function (maybe put them in a npm package so to avoid code duplication)

Depending on the volume of messages you’re dealing with, option 1 has a cost consideration given there’s a Lambda invocation per message (in addition to the polling function which is running non-stop).



So that’s it folks, it’s a pretty long post and I hope you find the ideas here useful. If you’ve got any feedbacks or suggestions do feel free to leave them in the comments section below.

AWS Lambda – use recursive function to process SQS messages (Part 1)

UPDATE 07/09/2016 : read part 2 on how to elastically scale Lambda function based on no. of messages available in the queue.



It’s been a year since the release of AWS Lambda service and here at Yubl we’re at the start of an exciting journey to move our stack to Lambda (using the awesome Serverless framework).

One feature that’s sadly missing though, is support for SQS. Every AWS evangelist I have spoken to tells me that it’s one of the most requested features from their customers and that it’s coming. It’s not the first time I have heard this kind of non-committal response from those involved with Amazon and experience tells me not to expect it to happen anytime soon.

But, if you’re itching to use AWS Lambda with SQS and don’t wanna wait an unspecified amount of time to get there, you have some options right now:

  • use SNS or Kinesis instead
  • do-it-yourself with recursive Lambda function that polls and processes SQS messages



TL;DR

Whilst you can use SNS and Kinesis with Lambda already, SQS‘s support for dead letter queues still makes it a better choice in situations where eventual consistency can be tolerated but outright data losses should be mitigated.

Whilst you can process SQS using EC2-hosted applications already, Lambda delivers a potential cost saving for low-traffic environments and more granular cost control as you scale out. It also provides an easy and fast deployment pipeline, with support for versioning and rollbacks.

Finally, we’ll walk through a simple example and write a recursive Lambda function in Node.js using the Serverless framework.



Lambda + SNS/Kinesis vs. Lambda + SQS

As a compromise, both SNS and Kinesis can be used with Lambda to allow you to delay the execution of some work till later. But semantically there are some important differences to consider.



Retries

SQS has built-in support for dead letter queues – i.e. if a message is received N times and still not processed successfully then it is moved to a specified dead letter queue. Messages in the dead letter queue likely require some manual intervention and you typically would set up CloudWatch alarms to alert you when messages start to pour into the dead letter queue.

If the cause is temporal, for example, there are outages to downstream systems – DB is unavailable, or other services are down/timing out – then the dead letter queue helps:

  1. prevent the build up of messages in the primary queue; and
  2. gives you a chance to retry failed messages after the downstream systems have recovered.

With SNS, messages are retried 3 times and then lost forever. Whether or not this behaviour is a showstopper for using SNS needs to be judged against your requirements.

With Kinesis, the question becomes slightly more complicated. When using Kinesis with Lambda, your degree of parallelism (discussed in more details below) is equal to the no. of shards in the stream. When your Lambda function fails to process a batch of events, it’ll be called again with the same batch of events because AWS is keeping track of the position of your function in that shard.

lambda+kinesis-v2

In essence, this means the retry strategy is up to you, but your choices are limited to:

  1. fail and always retry the whole batch (even if some messages were processed successfully) until either the fault heals itself or the messages in the batch are no longer available (Kinesis only keeps messages for up to 24 hours)
  2. never retry a failed batch

If you choose option 1 (which is the default behaviour), then you also have to ensure that messages are processed in a way that’s idempotent. If you choose option 2, then there’s a significant chance for data loss.

Neither option is very appealing, which is why I would normally use Kinesis in conjunction with SQS:

  • process a batch of messages, and queue failed messages into SQS
  • allow the processing of the shard to move on in spite of the failed messages
  • SQS messages are processed by the same logic, which required me to decouple the processing logic from the delivery of payloads (SNS, SQS, Kinesis, tests, etc.)



Parallelism

SNS executes your function for every notification, and as such has the highest degree of parallelism possible.

lambda-parallelism-sns-01

There’s a soft limit of 100 concurrent Lambda executions per region (which you can increase by raising a support ticket), though according to the documentation, AWS might increase the concurrent execution limit on your behalf in order to execute your function at least once per notification. However, as a safety precaution you should still set up CloudWatch alarms on the Throttled metric for your Lambda functions.



With Kinesis (and DynamoDB Streams for that matter), the degree of parallelism is the same as the no. of shards.

lambda-parallelism-kinesis

If you’re working with SQS today, the degree of parallelism would equal to the no. of poll loops you’re running in your cluster.

sqs-parallelism

For example, if you’re running a tight poll loop for each core, and you have 3 quad-core EC2 instances in a cluster, then the degree of parallelism would be 3 instances * 4 cores = 12.

Moving forward, if you choose to use recursive Lambda functions to process SQS messages then you can choose the degree of parallelism you want to use.



Lambda + SQS vs. EC2 + SQS

Which brings us to the next question : if you can use EC2 instances to process SQS messages already, why bother moving to Lambda? I think the cost saving potentials, and the ease and speed of deployment are the main benefits.



Cost

If you use the smallest production-ready EC2 class – Linux t2.micro – it will cost you $10.25/month in the eu-west-1 region (Ireland).

Whilst the auto-scaling service is free to use, the default EC2 health checks cannot be relied upon to detect when your application has stopped working. To solve this problem, you’ll typically setup an ELB and use ELB health checks to trigger application level checks to ensure it is still running and processing messages.

The ELB health checks also enables the auto-scaling service to automatically replace unhealthy instances.

A minimum production deployment would therefore cost you $30.75 a month.



A recursive Lambda function running non-stop 24/7 would run for 2678400 seconds a month.

60 s * 60 m * 24 hr * 31 days = 2678400 s

If you assign 128MB to your function, then your monthly cost for Lambda would be $5.61 a month.

Monthly Compute Charge

  = Total Compute (GB-seconds) * ($0.00001667 /GB-second)

  = (2678400 s * 128 MB / 1024 MB) * $0.00001667

  = 334800 GB-seconds * $0.00001667

  = $5.581116

Monthly Request Charge

  = Total Requests * ($ 0.20/Million Reqs)

  = (2678400 s  / 20 s) / 1000000 * $ 0.20

  = 133920 Req / 1000000 * $0.20

  = $0.026784

Monthly Charge (Total)

  = Monthly Compute Charge + Monthly Request Charge

  = $5.581116 + $0.026784

= $5.6079

Since Lambda’s free tier does not expire 12 months after sign up, this would fall within the free tier of 400000 GB-seconds per month too.



However, there are other aspects to consider:

  • you can process several SQS queues in one EC2 instance
  • the cost of ELB is amortised as the size of cluster increases
  • EC2 instance class jumps in cost but also offers more compute and networking capability
  • in order to auto-scale your SQS-processing Lambda functions, you’ll need to provision other resources

The exact cost saving from using Lambda for SQS is not as clear cut as I first thought. But at the very least, you have a more granular control of your cost as you scale out.

A recursively executed, 128MB Lambda function would cost $5.61/month, whereas an autoscaled cluster of t2.micro instances would go up in monthly cost $10.25 at a time.

lambda-vs-ec2-cost



Deployment

In the IAAS world, the emergence of container technologies has vastly improved the deployment story.

But, as a developer, I now have another set of technologies which I need to come to grips with. The challenge of navigating this fast-changing space and making sensible decisions on a set of overlapping technologies (Kubernetes, Mesos, Nomad, Docker, Rocket, just to name a few) is not an easy one, and the consequence of these decisions will have long lasting impact on your organization.

Don’t get me wrong, I think container technologies are amazing and am excited to see the pace of innovation in that space. But it’s a solution, not the goal, the goal is and has always been to deliver values to users quickly and safely.

Keeping up with all that is happening in the container space is overwhelming, and at times I can’t help but feel that I am trading one set of problems with another.

As a developer, I want to deliver value to my users first and foremost. I want all the benefits container technologies bring, but make their complexities someone else’s problem!



One the best things about AWS Lambda – besides all the reactive programming goodness – is that deployment and scaling becomes Amazon‘s problem.

I don’t have to think about provisioning VMs and clustering applications together; I don’t have to think about scaling the cluster and deploying my code onto them. I don’t have to rely on an ops team to monitor and manage my cluster and streamline our deployment. All of them, Amazon‘s problem!

All I have to do to deploy a new version of my code to AWS Lambda is upload a zip file and hook up my Lambda function to the relevant event sources and it’s job done!

Life becomes so much simpler

With the Serverless framework, things get even easier!

Lambda supports the concept of versions and aliases, where an alias is a named version of your code that has its own ARN. Serverless uses aliases to implement the concept of stages – ie. dev, staging, prod – to mirror the concept of stages in Amazon API Gateway.

To deploy a new version of your code to staging:

  • you publish a new version with your new code
  • update the staging alias to point to that new version
  • and that’s it! Instant deployment with no downtime!

Similarly, to rollback staging to a previous version:

  • update the staging alias to point to the previous version
  • sit back and admire the instant rollback, again with no downtime!

What’s more? Serverless streamlines these processes into a single command!



Writing a recursive Lambda function to process SQS messages with Serverless

(p.s. you can find the source code for the experiment here.)

First, let’s create a queue in SQS called HelloWorld.

recursive_sqs_01

Notice that although we have specified the default visibility timeout and receive message wait time (for long polling) values here, we’ll override them in the ReceiveMessage request later.

Then we’ll create a new Serverless project, and add a function called say-hello.

Our project structure looks roughly like this:

recursive_sqs_004

In the handler.js module, let’s add the following.

recursive_sqs_000

Notice we’re relying on two environment variables here – QUEUE_URL and FUNC_NAME. Both will be populated by Serverless using values that we specify in s-function.json (to understand how this works, check out Serverless’s documentation).



Next, we’ll write the handler code for our Lambda function.

Here, we will:

  1. make a ReceiveMessage request to SQS using long polling (20s)
  2. for every message we receive, we’ll process it with a sayHello function (which we’ll write next)
  3. the sayHello function will return a Promise
  4. when all the messages have been processed, we’ll recurse by invoking this Lambda function again

recursive_sqs_001

In the sayHello function, we’ll log a message and delete the message in SQS.

One caveat to remember is that, Promise.all will reject immediately if any of the Promises rejects. Which is why I’m handling any error related to deleting the message in SQS here with .catch – it’ll restore the chain rather than allowing the reject to bubble up.

recursive_sqs_002

This implementation, however, doesn’t handle errors arising from processing of the message (i.e. logging a message in this case). To do that, you’ll have to wrap the processing logic in a Promise, eg.

return new Promise((resolve, reject) => {

    // processing logic goes here

    resolve();

})

.then(() => SQS.deleteMessage(delParams).promise())

.then(…)

.catch(…);



Finally, let’s add a recurse function to invoke this function again.

recursive_sqs_003

Couple of things to note about this function:

  1. unlike sayHello, it doesn’t catch its own errors, this allows the reject to bubble up to the main handler function which will then fail the current execution
    • by failing the current execution this way we can use the Errors metric in CloudWatch to re-trigger this Lambda function (more on this in Part 2)
  2. we’re calling invokeAsync instead of invoke so we don’t have to (in this case we can’t!) wait for the function to return



Deploying the Lambda function

You’ll notice that we haven’t provided any values for the two environment variables – QUEUE_URL and FUNC_NAME – we mentioned earlier. That’s because we don’t have the ARN for the Lambda function yet!

So, let’s deploy the function using Serverless. Run serverless dash deploy and follow the prompt.

recursive_sqs_02

Aha, there’s the ARN for our Lambda function!

Go back to the project, open _meta/variables/s-variables-dev-euwest1.json and add the variables queueUrl and funcName.

recursive_sqs_03

However, there’s another layer of abstraction we need to address to ensure our environment variables are populated correctly.

Open processors/say-hello/s-function.json.

In the environment section, add QUEUE_URL and FUNC_NAME like below:

recursive_sqs_14

Now do you see how things fit together?

serverless-env-vars

Since we’ve made changes to environment variables, we’ll need to redeploy our Lambda function.



Testing the deployed Lambda function

Once your Lambda function is deployed, you can test it from the management console.

recursive_sqs_04

See that blue Test button on the top left? Click that.

Since our function doesn’t make use of the incoming payload, you can send it anything.

Oops.

If you run the function as it stands right now, you’ll get a permission denied error because the IAM role the Lambda service uses to call our function with doesn’t have permissions to use the SQS queue or to invoke a Lambda function.

That’s great, because it tells me I have granular control over what my Lambda functions can do and I can control it using IAM roles.

But we do need to go back to the project and give our function the necessary permissions.



Configuring execution role permissions

Back in the Serverless project, take a look at s-resources-cf.json in the root directory. This is a templated CloudFormation file that’s used to create the AWS resources for your function, including the execution role for your functions.

Wherever you see ${stage} or ${region}, these will be substituted by variables of the same name under _meta/variables/xxx.json files. Have a read of the Serverless documentation if you wanna dig deeper into how the templating system works.

By default, Serverless creates an execution role that can log to CloudWatch Logs.

{
  “Effect”: “Allow”,
  “Action”: [
    “logs:CreateLogGroup”,
    “logs:CreateLogStream”,
    “logs:PutLogEvents”
  ],
  “Resource”: “arn:aws:logs:${region}:*:*”
}

You can edit s-resources-cf.json to grant the execution role permissions to use our queue and invoke the function to recurse. Add the following statements:

{
  “Effect”: “Allow”,
  “Action”: [
    “sqs:ReceiveMessage”,
    “sqs:DeleteMessage”
  ],
  “Resource”: “arn:aws:sqs:${region}:*:HelloWorld”
},
{
  “Effect”: “Allow”,
  “Action”: “lambda:InvokeFunction”,
  “Resource”: “arn:aws:lambda:${region}:*:function:recursive-lambda-for-sqs-say-hello:${stage}”
}

We can update the existing execution role by deploying the CloudFormation change. To do that with Serverless, run serverless resources deploy (you can also use sls shorthand to save yourself some typing).

recursive_sqs_06

If you test the function again, you’ll see in the logs (which you can find in the CloudWatch Logs management console) that the function is running and recursing.



Now, pop over to the SQS management console and select the HelloWorld queue we created earlier. Under the Queue Actions drop down, select Send Message.

In the following popup, you can send a message into the queue.

recursive_sqs_07

Once the message is sent, you can check the CloudWatch Logs again, and see that message is received and a “Hello, Yan of message ID […]” message was logged.

recursive_sqs_08

and voila, our recursive Lambda function is processing SQS messages!

recurse-lambda-for-sqs-v0



In Part 2, we’ll look at a simple approach to autoscale the no. of concurrent executions of our function, and restart failed functions.
